Solid Waste Incineration and Hospital Incinerators for medical waste management
DF Series Waste Incinerator is a kind of machine that was developed on the basis of Japanese technology. It is an ideal choice for waste treatment of hospital, Farms,hotels , industries and various areas.
Main Features of Incinerator
(1) Gasified pyrolysis incineration is used for burning many kinds of waste.
(2) Gasified incineration, mixed incineration and burnout treatment ensures low emission standard of dust,doxin etc.
(3) Totally enclosed operation is suitable for treating infectious waste to avoid secondary pollution.
(4) Compact structure and small land occupation.
Technical Specification
Model | DF-30 | DF-50 | DF-150 | DF-300 | DF-500 |
Capacity | 20-30kg/time (3-6 times/d) | 30-50kg/time (3-6 times/d) | 100-150kg/time (3-6 times/d) | 200-300kg/time (3-6times/d) | 300-400kg/time (3-6times/d) |
Dimension (L*H*B) m | 1.45*0.9*1.75 | 1.8*1.15*3 | 2*1.4*3.5 | 2.2*1.4*3.8 | 3*2*4.8 |
Imputing Mouth Width (mm) | 480*600 | 620*800 | 760*960 | 900*1100 | 1080*1280 |
Chimney Diameter (mm) | 280 | 280 | 300 | 400 | 460 |
Fan Power | 0.25kw | 0.25kw | 0.37kw | 0.55kw | 0.55kw |
Oil Consumption | 4-6kg/h | 4-10kg/h | 4-10kg/h | 7-14kg/h | 7-14kg/h |
Voltage | 380V/220V | 380V/220V | 380V/220V | 380V/220V | 380V/220V |
Fuel | Diesel Oil/ LPG/ Nature Gas |
