Safety valves
The safety valves are pre-adjusted during assembly of the compressor and preventit being damaged in the event of a malfunction.The max pressure,as a function of the valve,asfollows:
1st stage safety valve 3,5Bar-(50PSI)
2nd stage safety valve 13Bar-(190PSI)
3rd stage safety valve 65Bar-(940PSI)
4th stage safety or final valve 225Bar-(3200PSI)/300Bar-(4300PSI)/330Bar-(4700PSI)
Main Parts of the Air Compressor
1 Frame
2 Pressure gauge
3 Hose
4 Refill valve
5 Internal combustion engine
6 Compressor
7 Oil filler cap
8 Air filter
9 Safety mesh
10 Anti-vibration devices
11 Cooling fan
12 Belt
13 Active carbon air filter / molecular sieve
14 Electric motor
15 Fuel tank
16 Internal combustion engine air filter
17 Internal combustion engine exhaust pipe
18 Safety valve
19 Condensate discharge
20 Condensate separator
